Fixed-wheel castor, Ø 50 mm, grey non-marking thermoplastic rubber tyre, 50KG

Product description

Ladder castors fixed castor made of pressed sheet steel, plate fitting, grey non-marking thermoplastic rubber tyre, conical ball bearing, Wheel Ø 50mm, 50KG

Ladder wheel:
This ladder wheel / suspended castor has a grey non-striping thermoplastic rubber tyre. This prevents streaking on your floors. The polyamide wheel core together with the precision ball bearing ensure that the ladder wheel can carry quite a few kilos. The wheel can be ordered in a castor and a fixed-wheel variant with different load capacities.

Advantages: When the castors are loaded, a spring is pressed down, making the ladder fixed to the ground. This makes the ladder wheel rollable up to 2 kg. But nailed to the ground when the wheel is loaded more heavily.

Applications: Although the wheels are mainly used under ladders, they can also be seen under stools, steps and doggies. At approx. 17 kg load, the spring is compressed by a maximum of 22 mm. The mounting plate can be rotated by 90°.

Suitable surface: The castors roll ideally on a flat surface or with minor unevenness. The non-striping belt can be used virtually all indoor floors such as ceramic tiles, linoleum, marble, concrete or parquet.

Suitable environment: Dry and not permanently damp. Can also be used with light acids and alkalis. This makes the ladder wheel suitable for (semi-)industrial environments.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

Fixed-wheel castor, Ø 50 mm, grey non-marking thermoplastic rubber tyre, 50KG

Ladder castors fixed castor made of pressed sheet steel, plate fitting, grey non-marking thermoplastic rubber tyre, conical ball bearing, Wheel Ø 50mm, 50KG

Delivery within 4 business days possible

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service
  • Estimated time: Delivery within 4 business days possible

Product information

  • SKU 776794500
  • EAN 8718116182993

Specifications

  • Non marking tread Yes
  • Wheel diameter 50
  • Wheelwitdh 18
  • Load capacity 50
  • Overall height 150
  • Size of top plate 59,5x48
  • Topplate hole centres 38x22,5
  • Plate hole 5,3
  • Bearing type Ball bearing
  • Tread description Grey thermo (TPR) rubber
  • Castor wheel type Bucket wheel
  • Fitting Plate mounting
  • Fork material Galvanised
  • Series 77.79
  • Tread Solid rubber
