flange wheel, Ø 200mm, cast iron wheel, 3000KG

Product description

narrow gauge wheel flange wheel from , , cast iron wheel, precision ball bearing, Wheel-Ø 200mm, 3000KG

cast iron wheel, with wheel core made of cast iron wheel, precision ball bearing,

Advantages: Single or double flange wheels made of special cast iron, in painted finish. The flange and tread are cleanly turned. The tread runs off the flange at an angle of 3 degrees. A grease nipple is fitted from a diameter of 150 mm. The wheels are available with plain or ball bearings.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

flange wheel, Ø 200mm, cast iron wheel, 3000KG

narrow gauge wheel flange wheel from , , cast iron wheel, precision ball bearing, Wheel-Ø 200mm, 3000KG

Delivery within 4 business days possible

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service
  • Estimated time: Delivery within 4 business days possible

Product information

  • SKU 100026202
  • EAN 8718116074861

Specifications

  • Wheel diameter 200
  • Load capacity 3000
  • Bearing type Ball bearing
  • Tread description Flange wheel made of high-quality cast iron. The track crown and tread are cleanly turned off. The tread descends from the track crown at an angle of 3 degrees.
  • Type of wheel Flange / Track / Diabolo wheels
  • Wheel width without flange 62
  • Wheel diameter inc flange 230
  • Hub length 90
  • Flange type 109
  • Diameter with flange 230
  • Flange Thickness / Width 18
  • Axle hole-Ø 40
  • Series 100.02
  • Tread Cast iron / steel
