swivel castor, Ø 160mm, elastic-tyre, 300KG

Product description

industrial swivel castor from pressed steel. bolt hole, elastic-tyre, 2-RS precision ball bearings, Wheel-Ø160mm, 300KG

industrial elastic rubber swivel castor

housing / bracket: pressed steel, double ball race in swivel head, bright zinc plated, blue passivated, bolt hole
wheel: elastic-tyre, with wheel centre from polyamide, 2-RS precision ball bearings, threadguards with labyrinth seal

Benefits: Versatile use with excellent rolling characteristics. Low noise and vibration damping, non-marking.

Applications: flight case, roll cage castor, trolleys for industrial handling, flight case , theatre & entertainment, blue elastic rubber

Suitable surface: Almost every surface: uneven surfaces such as pavers, damaged floors and obstacles such as thresholds.
Suitable environment: Dry and not permanently humid. For mild chemicals.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

swivel castor, Ø 160mm, elastic-tyre, 300KG

industrial swivel castor from pressed steel. bolt hole, elastic-tyre, 2-RS precision ball bearings, Wheel-Ø160mm, 300KG

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service

Product information

  • SKU 140566160G
  • EAN 8718116184843

Specifications

  • Non marking tread Yes
  • Wheel diameter 160
  • Load capacity 300
  • Overall height 190
  • Offset 52
  • Swivel Radius 132.0
  • Bearing type Ball bearing
  • Hardness of tread 80° Shore A
  • Tread description Wheel with grey elastic rubber tyre (vulcanised). Does not leave streaks on your floor.
  • Temperature -20 / +60°C
  • Castor wheel type Swivel castor
  • Fitting Bolt hole fixing
  • Fork material Galvanised
  • Fork Transport wheel Swivel fork with bolt hole fitting made of pressed galvanised sheet steel with double ball track in swivel head with dust seal and without central pin for extra stability
  • Bolt hole diameter 13
  • Series 40.56G
  • Tread Solid rubber
