castor, Ø 150 mm, Phenol wheel, 300KG

Product description
Quality & Service since 1946

wheel

Wheel: Made of high-quality Phenol resin for temperatures up to +280° C, highly impact-resistant hard running surface, Sliding bearing

Fork: Stainless AISI 304 fork with double ball race in the swivel head. swivel head with heat-resistant grease, plate fastening.

Stainless steel For various applications up to 280° C.

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

castor, Ø 150 mm, Phenol wheel, 300KG

wheel

Quantity

We want to make your work-life easier Tooltip Just tell us what you need
Fast delivery
3D CAD Models
Engineering service

Request special product

Download PDF

Chemical resistance

Product information

SKU 194760150
EAN 8718116186069

Specifications

Non marking tread Yes
Wheel diameter (mm) 150
Wheel witdh (mm) 45
Load capacity (kg) 300
Overall height (mm) 183
Size of top plate (mm) 135x110
Topplate hole centres (mm) 105x80
Mounting hole diameter (mm) 11
Swivel offset (mm) 52
Swivel Radius 127
Bearing type plain bearing
Tread description Heat-resistant wheel made of phenolic resin for temperatures up to 300°C.
Temperature -40 / +280°C
Castor wheel type Swivel castor
Fitting Plate mounting
Fork material Stainless steel AISI 304
Fork 194
Series 94.76 Heat-resistant Phenol wheel
Tread Plastic
