Fixed-wheel castor, Ø 150 mm, Phenol wheel, 300KG

Product description

wheel

Wheel: Made of high-quality Phenol resin for temperatures up to +280° C, highly impact-resistant hard running surface, Sliding bearing
Fork: Stainless AISI 304 fork with double ball race in the swivel head. swivel head with heat-resistant grease, plate fastening.

Stainless steel For various applications up to 280° C.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

Fixed-wheel castor, Ø 150 mm, Phenol wheel, 300KG

wheel

3-4 Weeks

Enter the number of articles below and click

Ok

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service
  • Estimated time: 3-4 Weeks

Request special product

Download PDF

Chemical resistance

Product information

  • SKU 294760150
  • EAN 8718116186076

Specifications

  • Non marking tread Yes
  • Wheel diameter (mm) 150
  • Load capacity (kg) 300
  • Overall height (mm) 183
  • Size of top plate (mm) 135x110
  • Topplate hole centres (mm) 105x80
  • Plate hole (mm) 11
  • Bearing type Sliding bearing
  • Tread description Heat-resistant wheel made of phenolic resin for temperatures up to 300°C.
  • Temperature -40 / +280°C
  • Castor wheel type Bucket wheel
  • Fitting Plate mounting
  • Fork material Stainless steel AISI 304
  • Fork 294
  • Series 94.76 Heat-resistant Phenol wheel
  • Tread Plastic
