swivel castor, Ø 100mm, vulcanized polyurethane tread, 200KG
industrial polyurethane (PU) swivel castor
housing / bracket: pressed steel, double ball race in swivel head, bright zinc plated, blue passivated, top plate fitting
wheel: vulcanized polyurethane tread, with wheel centre from aluminium, precision ball bearing,
Benefits: For medium heavy transport on smooth floors. Low rolling resistance. Relatively insensitive to cut and tear propagation resistance and very durable. Non-marking, quiet operation. Smooth surface, hygienic.
Applications: Industrial carts, material handling in factories, waste containers, transport containers, metal working and chemical companies, medium load roll containers, tool trolleys, warehouse carts.
Suitable surface: Smooth and hard surface such as tiles, cement and coatings.
Suitable environment: Both indoors and outdoors. For alcohol, glycol, mineral oils and fats.
housing / bracket: pressed steel, double ball race in swivel head, bright zinc plated, blue passivated, top plate fitting
wheel: vulcanized polyurethane tread, with wheel centre from aluminium, precision ball bearing,
Benefits: For medium heavy transport on smooth floors. Low rolling resistance. Relatively insensitive to cut and tear propagation resistance and very durable. Non-marking, quiet operation. Smooth surface, hygienic.
Applications: Industrial carts, material handling in factories, waste containers, transport containers, metal working and chemical companies, medium load roll containers, tool trolleys, warehouse carts.
Suitable surface: Smooth and hard surface such as tiles, cement and coatings.
Suitable environment: Both indoors and outdoors. For alcohol, glycol, mineral oils and fats.
Product Nr. | 146416101 |
---|---|
Streepvrije band | Ja |
Wiel diameter (mm) | 100 |
Wiel breedte (mm) | 38 |
Draagvermogen (kg) | 200 |
Bouwhoogte (mm) | 128 |
Plaatafmeting (mm) | 105x80 |
Boutgat afstand (mm) | 80x60 |
Bevestigingsgat (mm) | 9 |
Uitslag (mm) | 37 |
Uitzwenking + wiel | 87 |
Lager type | Kogellager |
Hardheid van de band | 95° Shore A |
Temperatuur | -20 / +60°C |
Velgenmateriaal | Gemaakt van hoogwaardig gegoten aluminium, corrosiebestendig |
Type wiel | Zwenkwiel |
Bevestiging | Plaatbevestiging |
Materiaal vork | Verzinkt |
Vork | Transportwiel Zwenkvork met plaatbevestiging gemaakt van geperst gegalvaniseerd plaatstaal. Met centrale bout dubbele kogelbaan in zwenkkop en stofafdichting |
Op voorraad
